Usage
●It is suitable for adults and adolescents in the dilation operation of digestive tract stricture under endoscopes.
Characteristics
●The balloon can be graduall increased at three distinct diameters under specific pressure,providing much more choice for physicians.
●Elastic soft tip design,which can smoothly enter into the target position with less damage.
●Rapid drainage design helps to reduce surgery time.
●Use imported material with high pressure resistance and safer dilation.
●Thermostatic shaping after multi-wing pleating contributes to excellent resilience and flexible retreat from working channel.
●Optimal design of the tube makes it smooth and of good elasticity,strong twisting resistance and easier passability.
● The radiopaque markers on the both ends of the balloon can provide precise positioning under X-ray.
●Pre-input 0.035"guide wire with soft tip and mark,which is easier to estimate the length of the inside guide wire.
Specifications(Unit:mm)
For Esophagus/Pylorus/Colonic
|
Model |
Working Channel |
Working Length |
Balloon Diameter |
Balloon Length |
Guide Wire |
|
BD-28N-0640 |
≥2.8 |
1800 |
06 |
40 |
0.035" |
|
BD-28N-0840 |
≥2.8 |
1800 |
08 |
40 |
0.035" |
|
BD-28N-1040 |
≥2.8 |
1800 |
10 |
40 |
0.035" |
|
BD-28N-1260 |
≥2.8 |
1800 |
12 |
60 |
0.035" |
|
BD-28N-1460 |
≥2.8 |
1800 |
14 |
60 |
0.035" |
|
BD-28N-1680 |
≥2.8 |
1800 |
16 |
80 |
0.035" |
|
BD-28N-1880 |
≥2.8 |
1800 |
18 |
80 |
0.035" |
|
BD-32U-2060 |
≥3.2 |
2300 |
20 |
60 |
0.035" |
|
BD-32U-2080 |
≥3.2 |
2300 |
20 |
80 |
0.035" |
For biliarytract
|
Model |
Working Channel |
Working Length |
Balloon Diameter |
Balloon Length |
Guide Wire |
|
BD-28Q-0640 |
≥2.8 |
2000 |
06 |
40 |
0.035" |
|
BD-28Q-0840 |
≥2.8 |
2000 |
08 |
40 |
0.035" |
|
BD-28Q-1040 |
≥2.8 |
2000 |
10 |
40 |
0.035" |
|
BD-28Q-1260 |
≥2.8 |
2000 |
12 |
60 |
0.035" |
|
BD-28Q-1460 |
≥2.8 |
2000 |
14 |
60 |
0.035" |
For choledochofiberscope
|
Model |
Working Channel |
Working Length |
Balloon Diameter |
Balloon Length |
Guide Wire |
|
BD-20A-0640 |
≥2.0 |
900 |
06 |
40 |
0.032" |
|
BD-20A-0840 |
≥2.0 |
900 |
08 |
40 |
0.032" |
|
BD-20N-0640 |
≥2.0 |
1800 |
06 |
40 |
0.032" |
|
BD-20N-0840 |
≥2.0 |
1800 |
08 |
40 |
0.032" |
